TP-LINK BE6500/7DR6560 Specifications and Stock Firmware

I. Specifications

|||| |—|—| |Wi-Fi|IEEE 802.11a/b/g/n/ac/ax/be| ||Maximum wireless rate 6500Mbps (2.4GHz 689Mbps, 5GHz 5765Mbps)| ||Beamforming| ||4×4 MU-MIMO| ||Wi-Fi multi-frequency combination| ||Multi-Link Operation (MLO)| ||Preamble puncture| |Ethernet ports|4 × 2.5Gbps (the four ports share a maximum of 5Gbps)| |Dimensions|293 × 264 × 72 mm; weight 620g| |Antenna type|2 dual-band antennas, 4 5GHz antennas| |Software|Bridge (wireless repeater)
Signal conditioning
Terminal management
IP and MAC address binding
AP isolation
Virtual server
Dynamic Domain Name Service (DDNS)
DMZ host
Automatic cleaning
Wireless time switch
Local online/local firmware/remote upgrade| |Power|12V, 2.5A|

See the inside of the TP-LINK BE6500/7DR6560 here.

II. Stock firmware

|||| |—|—| |Version|1.0.16| |Update date|January 13, 2024| |Download|Official link| |Support and update checking|Tplink.com.cn|

A Vietnamese seller was offering this router on Shopee. On January 16, 2024, the price was 2,555,000 VND; check the listing.
